Deuterium tungsten fiber optic lamp

Product Features

Ultra high-density fanout cables in a MTP to 6 x LC Duplex connector configuration
Made using high-quality OM4 fibre cable
Quality controlled to rigorous standards & tested using advanced fibre interferometer equipment
Ensures reliable & high-performance network connections

Next day delivery Order by 4pm Monday - Friday

Free delivery on orders over £50 (terms apply)

Introduction UV/VIS/NIR light source, spectrum range of 200~2500nm, SMA905 standard interface, small size, flue gas detection, water quality analysis, scientific research Feature ◆ The spectral range covers 200-2500nm; ◆ Manual or TTL signal to control the shutter; ◆ Separate deuterium lamp and tungsten lamp on and off; ◆ Compact, high stability, long life. Description Specifications Item Value Wavelength range 200~410 nm(Deuterium lamp);350~2500 nm(Tungsten lamp) Output 3.8W(Deuterium lamp);1.2W(Tungsten lamp) Stability 0.25%/h Time to stabilize 10 min(Deuterium lamp);10min(Tungsten lamp) Life Deuterium lamp:2000hrs;Tungsten lamp:6000hrs Delay time <2.0s(It takes longer when the temperature is low) Trigger control TTL Connector SMA 905 Numerical aperture 0.245@氘灯 Fiber core 200 – 1000um Power requirement 600mA @ 12 VDC Input voltage 12V/2A Dimensions 190x105x78mm
